PXI硬件在环解决方案用于故障注入测试和传感器仿真

我们理解汽车军事和航空航天行业具有最严苛的电子测试要求。超过25年来,我们已经设计和生产出商用和定制开关系统、以及仪器,广泛应用于设备功能测试和硬件在环仿真,为汽车和军事与航空航天电子的测试和验证提供帮助。

我们的硬件在环仿真应用包括:

  • 故障注入测试 - 引入电子故障到系统内 - 这项测试流程通常复制各种会发生的条件,例如由于年限、磨损或错误安装而造成的腐蚀、短/开路以及其它电子故障。
  • 传感器仿真 - 硬件在环系统用于测试ECU,尽可能准确地仿真这些传感器的行为以确保ECU的行为在实际应用中的和测试台上的一样。请阅读我们的PXI可编程电阻模块如何帮助测试系统设计者实现这些目标。

硬件在环目录下载(PDF)

  PXI Solutions for Hardware-in-the-Loop

当ECU出错时,它是谁的故障?

Electronic Control Units (ECUs) are ever-present in today's automotive and aerospace industries. They are increasingly being used in safety-critical applications that demand the highest reliability in environments where undesirable behavior cannot be tolerated - the failure of an ECU to act in an appropriate manner under emergency conditions could pose a threat to life and/or property. Ensuring these demands are unconditionally met requires significant investment in test procedures and documentation.

An ECU relies on information from a set of sensors and controls to decide what to do with the device it is managing. These sensors are themselves often working in extremely hostile environments (e.g. car or jet engines) and predictably failures can occur in the sensors or their interconnections. The ECU has to respond appropriately to these component failures as well as to genuine system faults. A jet engine needs to shut down if it catches on fi re, but should not shut down if it is clear there is a sensor fault.

Another example of an ECU operating in a hostile environment is the automotive Powertrain Control Modules (PCMs). The PCM is one of the most complex controllers in the modern vehicle and therefore requires rigorous testing of its functionality. The consequences of PCM failure have greater significance in X-by-Wire applications (a collective term for the addition of electronic systems into a vehicle to enhance and replace tasks that were previously accomplished via mechanical and hydraulic systems such as braking or steering), placing increased importance upon these test methods.

In addition to these fault insertion switch and sensor simulation products, we also offer a comprehensive range of supporting products:

Switch Simulation - An important test of automotive ECUs is to see if the inputs respond to switches that are dirty and do not present a normal open/closed resistance. Our modules are designed to simulate the operation of automotive switches where dirty contacts or leaking current can be expected from switch contamination. This allows automotive input/output (I/O) devices to be tested for correct operation under adverse conditions. Load Management The testing and verification of electrical and electronic systems often requires the connection of high current loads to the Unit Under Test (UUT). We provide a wide range of switch modules that can support up to 40 Amp load switching within a PXI chassis. For higher current requirements, our relay driver modules allow the test system to control external relays.
Digital I/O -  Our digital I/O modules allow you to interface directly with high current loads such as solenoid coils. These modules have fully protected outputs that can withstand high current and voltage surges without damage and include thermal protection, ensuring that even long term connection to a faulty load will not cause instrumentation damage. Our digital inputs feature adjustable dual thresholds that allow you to easily establish if a digital input is in a low high or unpredictable state. Their high input voltage capacity makes them an excellent choice for monitoring systems working from high voltage power supplies commonly found in aerospace applications. Communication Protocols - ECUs communicate with other system components for functionality, diagnostics and human interface via one or more serial bus channels. We have partnered with industry expert Ballard Technology to offer a family of products which take avionics databus interfaces to the highest level of flexibility and power. These modules support high channel counts of single or multiple protocols. In addition, our automotive communications module can support up to 10 CAN channels as well as other automotive protocols and physical layer interfaces.
Signal Conditioning -  Most PXI signal/arbitrary waveform generators lack the amplitude necessary to drive signals that simulate peripherals. Typically, additional circuitry needs to be added to the test fixture to amplify the output of the instrument. Our  multi-channel, gain selectable amplifiers work with many instruments including our  function generator . The attenuator module features selectable input ranges that accept up to 600 volt waveforms. RF and Microwave - we offer an extensive range of RF switching products, with PXI solutions ranging from 300MHz high density modules through to high performance 3GHz multiplexers, solid state and microwave switches to 65GHz. We also offer a programmable attenuator from DC to 3GHz with an attenuation depth of 63dB in 1 dB steps.
Environmental Testing - Testing of complex systems in a environmental chamber requires sharing the external instrumentation/ resources to stimulate and collect data from the UUTs over the cycles of the test. Our BRIC™ high density switch matrix  module can provide over 4,400 cross-points in eight PXI slots with configurations up to 552 x 8 and 1104 x 4. Cable & Connector Solutions - Pickering Interfaces understands that just providing switching and instrumentation modules is not enough - users need to be provided with fast and effective ways of connecting their investment to the device under test. The modules in our PXI and LXI families are fully supported by our comprehensive range of connector and cable accessories.

To learn more about products or please  contact us .
